Giant TCR Advanced 1 PC

$4,999.00
Colour: Asphalt Green
Size
Add to Cart
  • techs & features
  • geometry
  • specs
  • similar products
  • you may also like
  • BUILT TO GO FASTER. WHETHER YOU'RE CLIMBING, CORNERING OR LAUNCHING AN ATTACK, THIS ALL-NEW COMPOSITE ROAD RACER IS MADE FOR THAT MOMENT. LIGHTWEIGHT, EFFICIENT, AND INTEGRATED FOR SPEED, IT'S ENGINEERED TO GIVE YOU A COMPETITIVE EDGE IN EVERY SITUATION.


    KEY PERFORMANCE FACTORS

    SYSTEM OPTIMIZATION

    The frameset, wheels, cockpit and other parts were engineered, developed and tested together to perform as a system. The all-new Contact AeroLight stem allows for cable routing that integrates the top cap, cables and spacers in a more aerodynamic, user-friendly setup.


    WINNING EFFICIENCY

    Featuring a greater stiffness-to-weight ratio than the previous generation, along with new aero tube shaping and a lighter overall weight, this uncompromising race bike delivers explosive acceleration and unyielding pedaling stiffness. The result is race-winning performance in the moments that count.


    INTEGRATED AERODYNAMICS

    All tube shapes were engineered and developed using Computational Fluid Dynamics (CFD) modeling and wind-tunnel testing. From the truncated ellipse shape of frameset tubing to a new cockpit design and component integration, it all adds up to a more streamlined profile that improves overall aero performance compared to the previous generation.


    MADE FASTER

    Newly integrated components including the Contact AeroLight stem create a sleeker, more aero profile. The Variant seatpost adds just enough compliance for a balanced, race-tuned feel on the road, while generous tire clearance (up to 33mm) and compliant wheels keep you rolling with speed on smooth or bumpy roads.

  • TECHS & FEATURES

    ×

    ADVANCED COMPOSITE TECHNOLOGY

    Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and moulded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.

    ×

    COMPACT ROAD DESIGN

    Introduced by Giant with the professional Team ONCE in the 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.

    ×

    TUBELESS SYSTEM

    Fewer flat tyres. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.

    READ MORE

  • SIZING GUIDE AND GEOMETRY

    Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
    Available sizes may vary from country to country.

    XS
    S
    M
    ML
    L
    XL
    A SEAT TUBE LENGTH (mm)
    425
    445
    470
    500
    530
    560
    B SEAT TUBE ANGLE
    74.5°
    74.0°
    73.5°
    73.0°
    73.0°
    72.5°
    C TOP TUBE LENGTH (mm)
    520
    535
    550
    565
    580
    600
    D HEAD TUBE LENGTH (mm)
    120
    130
    145
    165
    185
    200
    E HEAD TUBE ANGLE
    71.0°
    72.3°
    73.5°
    73.0°
    73.0°
    72.5°
    F FORK RAKE (mm)
    45
    45
    45
    45
    45
    45
    G TRAIL (mm)
    72
    64
    59
    59
    59
    59
    H WHEELBASE (mm)
    976
    977
    980
    991
    1006
    1020
    I CHAIN STAY LENGTH (mm)
    405
    405
    405
    405
    405
    405
    J BOTTOM BRACKET DROP (mm)
    72
    69.5
    69.5
    67
    67
    67
    K STACK (mm)
    517
    528
    545
    562
    581
    596
    L REACH (mm)
    376
    383
    388
    393
    402
    412
    M STAND OVER HEIGHT (mm)
    703
    722
    743
    771
    798
    822
    O STEM LENGTH (mm)
    80
    90
    100
    110
    110
    120
    P CRANK LENGTH (mm)
    170
    170
    172.5
    172.5
    175
    175
    Q WHEEL SIZE
    700C
    700C
    700C
    700C
    700C
    700C
  • Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products with your local retailer at the time of sale if purchasing in-store. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs.
